DYNAMIXEL XH540-W150-R

DYNAMIXEL-X

SKU:

902-0138-000

UPC:

8809052935177

Weight:

0.70 LBS

Shipping:

Calculated at Checkout

Rated Torque:

1.42N

No Load RPM:

70RPM

Dimensions:

33.5x58.5x45mm

Supported Baudrades:

9,600 ~ 4.5MBaud

Resolution:

4096 Steps

Backlash:

15 arcminutes

Weight:

165g

Input Voltage:

12v

Standby Current:

40mA

Stall Current:

4.9A

Operating Modes:

Current Control Mode, Velocity Control Mode, Position Control Mode, Extended Position Control Mode, Current Based Position Control Mode, PWM Control Mode

Communications Protocol:

RS485

Radial Load Limit:

40N

Axial Load Limit:

20N

Stall Torque:

7.1

Size:

X540

Special Features:

External Input Port, Dual Joint Port
